| Input (PV) |
|
| Max. power(kW) | 7.5 | 9 | 12 | 13 |
| MPPT voltage range(V) | 125~500 |
| MPPT tracker/strings | 4/1 |
| AC output |
|
| Rated output power(kVA) | 5 | 6 | 8 | 10 |
| Grid voltage/range(V) | 120/240 (split phase)，208 (2/3 phase), 230 (single phase) |
| Frequency (Hz) | 50 /60 |
| THDi | <3% |
| Battery |
|
| Battery voltage range(V) | 40~58 |
| Max. charge/discharge current(A) | 120/120 | 135/135 | 190/190 | 210/210 |
| Communication interface | CAN/RS485 |
| EPS output |
|
| Rated power (kVA) | 5 | 6 | 8 | 10 |
| Rated output voltage(V) | 120/240 (split phase)，208 (2/3 phase), 230 (single phase) |
| Automatic switching time (ms) | <20 |
| General data |
|
| DC Max. efficiency | ≥98.2% |
| Dimensions W * D * H (mm) | 430*220*710 |
| Weight（kg） | 41 |
| Certificates | UL1741SA all options, UL1699B, CSA 22.2 |
